TL1 Commands, Autonomous Messages, and Error Codes Supported by the NCU
This section lists the specific TL1 commands and autonomous messages (in alphabetical order) the NCU supports. Also provided is a list
of error codes for the TL1 commands supported.
NOTE: The NCU does not currently support parameter grouping in TL1 commands.
NOTE: In response messages, only the completion codes ‘COMPLD’ and ‘DENY’ are used.
FORMAT OVERVIEW OF REQUIRED TL1 MESSAGES
Command Message Overview
This tables summarize the format of the supported TL1 requests.
verb[-modifier[-modifier]:[<tid>]:[<aid>]:<ctag>[:[general block][:input parameter blocks]];
Verb-
modifier(s)
Description
<tid>
<aid>
<ctag>
general
block
parameter
blocks
ACT-USER
User logon request.
<null>
or the
system
identifier
User-id
Correlation
tag
not used
Password
CANC-USER
User logoff request.
User-id
not used
RTRV-ALM-
{ALL|EQPT}
Requests all alarms or
only those specified in
parameter blocks.
ALL
or
specified
varies
RTRV-EQPT
Requests information on
specified equipment.
ALL
or SYSTEM
not used
RTRV-HDR
Requests a system
header message.
<null>
not used
REPT-ALM-EQPT
Report of alarms as they
occur and clear.
--
varies
CANCEL-
SESSION
User timeout message.
<null>
not used
