NOTE: The relay test can be exited at any time by setting the
Relay Test to Disabled.
Manual Test
When placed in Relay Manual Test Mode, all relays on an IB2 board,
EIB board, and NCU de-energize (since Fail Safe is enabled relay 1
on the 1st IB2 will be in alarm state, if wired for fail safe). Then you
can individually change each relay’s state. The relay changes state
for the time period selected. At the end of the test, all relays are
returned to their normal state (if no alarms are present). This is the
same procedure as “Manually Forcing Relays” on page 23 except
you do not place the controller in Manual Mode.
Local Menu Navigation:
None.
WEB Menu Navigation:
Settings Menu / System Tab / Relay Test (set to Manual).
or
Advance Settings Menu / DO (Relay) Tab / Relay Test (set to
Manual).
then
Advance Settings Menu / DO (relay) / Relay (select the other state)
then press the SET button.
then
Settings Menu / System Tab / Relay Test (set to Disabled).
or
Advance Settings Menu / DO (Relay) Tab / Relay Test (set to
Disabled).
Clearing the Maintenance Alarm
A maintenance time can be set which, once expires, issues a
maintenance alarm. When the maintenance alarm is issued,
perform the routine maintenance and reset the maintenance
timer. To reset the maintenance timer and clear the Maintenance
Alarm, clear the Maintenance Run Time.
Local Menu Navigation:
None.
WEB Menu Navigation:
Settings Menu / System Tab / “Auto/Manual” State (change to
Manual).
then
Settings Menu / System Tab / Clear Maintenance Run Time.
then
Settings Menu / System Tab / “Auto/Manual” State (change to
Auto).
Performing a Manual Battery Discharge Test
Procedure
1. Check that the Rated Battery Capacity is set up correctly
for each battery.
Local Menu: Main Menu / Settings Icon / Batt Settings /
Battery Test.
Web Menu: Settings Menu / Battery Test
2. Check that the following Battery Test parameters are set
correctly: Test Voltage Level, End Test Voltage, End Test
Time, End Test Capacity, Record Threshold.
Local Menu: Main Menu / Settings Icon / Batt Settings /
Battery Test.
Web Menu: Settings Menu / Battery Test / Battery Test
Control.
3. Start the battery discharge test.
Local Menu: Main Menu / Settings Icon / Maintenance /
BattTestControl.
Web Menu: Settings Menu / Battery Test / Battery Test
Control.
4. Wait for the test to end.
5. View the battery test log and upload it to your computer
as required. See “Battery Test Log Tab” on page 134.
Updating the NCU Controller’s Device Inventory
Local Menu Navigation:
Main Menu / Settings Icon / Other Settings / Auto Config.
Web Menu Navigation:
Advance Settings Menu / SW Maintenance Tab / Auto Config.
Backing Up the NCU Configuration
There are two steps in backing up the system’s NCU configuration:
 Save the NCU configuration package. This package
includes the base configuration and any changes made to
alarm severity levels, relay assignments, signal names
and site information.
 Save a file named "SettingParam.run". This file contains
changes made to alarm setpoints and other settings such
as float/ equalize voltage, etc. A file named
"SettingParam.run" is automatically created/appended by
the controller whenever a User (or the factory at the time
of shipment) makes changes to parameter settings via
the local display or Web Interface. This file can be saved
