Vertiv Netsure User Manual

NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
[130]
 Confirm Solar Converter ID: After changing solar converter ID assignments, use this menu item to confirm the change. The
only selection is Yes. Once Yes is selected and confirmed, the ID setting of all solar converters is updated.
 Reset Solar Converter IDs: Resets the solar converter IDs after they have been previously changed and confirmed. The only
selection is Yes. Once Yes is selected and confirmed, the NCU resets the solar converter IDs by reassigning ID numbers.
 Clear Solar Converter Comm Fail: Clears a solar converter communication fail alarm. The only selection is Yes. Once Yes is
selected and confirmed, the alarm clears.
 Clear Solar Converter Lost Alarm: Clears a solar converter lost alarm. The only selection is Yes. Once Yes is selected and
confirmed, the alarm clears.
Battery Test Tab Programmable Parameter Descriptions
 Battery Test Control: Starts or stops battery test.
 AC Fail Test: Enables or disables starting a battery discharge test during an AC input failure condition.
 Constant Current Test: Enables or disables a Constant Current Battery Discharge Test. During this test, the controller
automatically adjusts the rectifiers' output voltage to maintain the battery discharge current at a preset value (Constant Current
Test Current).
 Constant Current Test Current: Constant current setting for a Constant Current Battery Discharge Test.
 Short Test: Enables or disables a Short Battery Discharge Test. A Short Battery Discharge Test is a short duration battery
discharge test used to verify that parallel batteries are discharging equally. If the discharge current difference between the two
batteries exceeds a preset value, an alarm is generated.
NOTE: This test requires a system with two battery shunts.
 Short Test Cycle: Short Battery Discharge Test interval (days).
 Short Test Time: Short Battery Discharge Test time (minutes).
 Short Test Max Difference Current: An alarm is generated if the maximum difference between discharge currents of the two
batteries exceeds this limit.
 Test Voltage Level: System output voltage setting during a battery discharge test.
 End Test Voltage: This is the "end of test voltage level" for battery discharge tests. A battery discharge test will end if battery
voltage decreases to this setting.
 End Test Time: This is the "end of test time period” for battery discharge tests. A battery discharge test will end if this time
period is exceeded.
 End Test Capacity: This is the "end of test remaining battery capacity" for battery discharge tests. A battery discharge test will
end if remaining battery capacity decreases to this setting. For example, a value of 0.700C10 means that when the discharging
current reaches 70% of the battery's nominal capacity, the battery test is ended.
 Record Threshold: Every time the battery voltage is changed more than this threshold, a new line is stored in the battery test
log.
 Number of Planned Tests per Year: Number of planned battery discharge test per year. There can be up to twelve (12) battery
discharge tests per year. A "0" setting disables the planned test feature.
 Planned Test # (MM-DD Hr): Setting for when planned battery discharge test # occurs. Note that there can be up to twelve (12)
battery discharge tests per year.
 Clear Bad Battery Alarm: Clears a bad battery alarm. The only selection is Yes. Once Yes is selected and confirmed, the alarm
clears.
