NetSure
™
Control Unit (NCU)
User Manual, UM1M830BNA
Spec. No: 1M830BNA, 1M830DNA Code: UM1M830BNA
Model No: M830B, M830D Revision M, May 12, 2017
PARAMETER SETTING IN SNMP MANAGER
MIB Installation
INSTALLATION
The Controller’s MIB is named "Netsure-NCU.mib". Contact your
Vertiv representative for the location on the Web to download the
MIB file.
Use the MIB loading function of the NMS to load the MIB database.
Refer to the User Manual provided with the NMS for the detailed
loading method.
CONTENTS OF THE CONTROLLER’S MIB
The contents of the MIB supported by the controller's SNMP agent
and the OID are listed in Table 7. For the details, refer to the MIB
file named "Netsure-NCU.mib".
Accessing the Controller through an NMS
APPLY ADMINISTRATIVE PRIVILEGE
In order to use the NMS to manage the devices connected to the
controller, the administrative authority needs to be applied for the
NMS, that is, add the NMS information to the access list of SNMP
agent.
Add NMS through Web Browser
Refer to “NMSV2 Configuration Description (Network
Management System)” on page 148 and “NMSV3 Configuration
Description (Network Management System)” on page 149 for the
method of adding NMS.
ESR Configure
The EEM Protocol is used for communication between the Main
Computer and the controller. The Main Computer is the computer
superior to the NCU (the client of the NCU). On this page, all
parameters needed for communication with a main EEM computer
are to be set.
User Information Configuration: On this page, Users, their
privilege and password are configured.
Time Synchronization: On this page, the system time and date are
to be set.
Automatic time synchronization from time servers can also be
configured.
The User permitted to access the agent.
The get/set data security level
(NoAuthNoPriv, AuthNoPriv, or
AuthPriv).
The private DES password used to
encrypt the data.
The authorization MD5 password
used to encrypt the digital
signature.
