♦ Torque wrench -V.A.G 1410-
Removing
– Separate connection -1-.
– Remove bolts -2- from lower transverse link.
– Remove bolts -arrows- from subframe.
– Remove rear left vehicle level sender -G76- .
Installing
Install in reverse order. Note the following points:
The lever of rear left vehicle level sender -G76- must face outside
of vehicle.
– After completing installation, carry out basic setting of head‐
lights ⇒ "Guided fault-finding" function of vehicle diagnosis,
testing and information system VAS 5051 .
Specified torques
Component Specified torque
Rear left vehicle level sender -G76- to lower transverse link
and subframe
5 Nm
3.4 Removing and installing upper trans‐
verse link
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1332-
Removing
– Remove wheel.
– Remove coil spring ⇒ page 173 .
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
3. Assembly overview: subframe, transverse link, track rod (front-wheel drive) 149
