❑ Always tighten threaded connections in unladen position ⇒ page 187
26 - Nut
❑ M12 x 1.5
❑ 90 Nm + 90° further
❑ Self-locking
❑ Always renew after removing
11.1 Overview - rear left vehicle level sender -G76-
Note
♦ The vehicle level sender is available as a replacement part only complete with coupling rod and upper and
lower retaining plates.
♦ Renewing without removing subframe ⇒ page 215 .
♦ Control unit for headlight range control -J431-
1 - Subframe
2 - Lower transverse link
3 - Bolt
❑ 5 Nm
4 - Rear left vehicle level send‐
er -G76-
❑ Complete with attach‐
ments
❑ Lever -arrow- must face
outwards
❑ Renewing in vehicle
⇒ page 215
❑ Allocation ⇒ Electronic
parts catalogue “ETKA”
❑ Following renewal, ba‐
sic settings for headlight
must be performed.
Basic setting of headlights ⇒
"Guided fault-finding" function
of vehicle diagnosis, testing
and information system
VAS 5051
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
214 Rep. Gr.42 - Rear suspension
