Time for which the button is pressed
Up to 2 seconds 3-7 seconds 8-10 seconds 11-15 seconds
State or action Actual state Switch Confirm Deactivation
Deactivation Full tyre load moni‐
tored
or
Partial tyre load
monitored
(gong)
Partial tyre load on!
or
Full tyre load on!
TPM off!
(gong)
Status query For example:
TPM off!
or
Partial tyre load
monitored
(gong)
After releasing:
Press longer to acti‐
vate!
or
Press longer to
switch or deactivate!
7.2 Assembly overview - tyre pressure sensor
1 - Tyre pressure sensor
❑ Supplied complete as
spare part.
❑ Removing and installing
⇒ page 304
❑ Replace complete tyre
pressure sensor when
battery is dead
❑ After using breakdown
set, wipe clean hole for
valve and opening for
pressure sensor
2 - Valve core
❑ Allocation ⇒ Electronic
parts catalogue “ETKA”
❑ Always renew when
changing tyre
Note
3 - Sealing washer
4 - Sealing ring
❑ Will be slightly deformed
when the union
⇒ Item 6 (page 303) nut
is tightened
5 - Wheel
❑ Fitting tyres of wheels
with tyre pressure mon‐
itoring ⇒ page 290
❑ Fitting tyres with run-flat
capabilities ⇒ page 294
6 - Union nut
❑ 8 Nm
7 - Valve cap
❑ Use only genuine valve caps from repair set ⇒ Electronic parts catalogue “ETKA” .
