10 Assembly overview - subframe made from steel, final drive (four-wheel
drive)
-Arrow- indicates direction of travel.
1 - Subframe
2 - Rear bonded rubber bush
❑ Renewing ⇒ page 205
3 - Front bonded rubber bush
❑ Renewing ⇒ page 205
4 - Final drive
❑ Removing and installing
⇒ Rep. Gr. 39 ; Remov‐
ing and installing rear fi‐
nal drive .
5 - Bolt
❑ M12 x 105
❑ 60 Nm + 90° further
❑ Renew each time after
removing
6 - Washer
❑ Installed between final
drive and subframe.
7 - Washer
❑ Washer must be placed
with holes on lugs of
bonded rubber bush.
8 - Bolt
❑ M12 x 105
❑ 60 Nm + 90° further
❑ Renew each time after
removing
10.1 Removing and installing rear axle
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1332-
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
10. Assembly overview - subframe made from steel, final drive (four-wheel drive) 199
