– Attach tools as shown in figure.
1 - -3346/3-
2 - -3301-
3 - -30-506 B-
4 - Bonded rubber bush
5 - -3160-
6 - -3350/2-
7 - -3346/2-
– Pull in bonded rubber bush by turning spindle.
Note
♦ Do not use lubricant.
♦ Install bonded rubber bush carefully so that it does not cant.
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
The threaded connections on the wheel bearing housing may be
tightened only when the dimension measured between the centre
of wheel hub and lower edge of wheel housing before work was
started has been attained ⇒ page 188 .
Specified torques
Component Specified torque
Wheel bearing housing to lower suspension link
♦ Use new nuts and bolts
♦ Tighten threaded connections only when vehicle is in
the normal running position.
90 Nm + 90°
Splash plate to wheel bearing housing 10 Nm
Brake disc to wheel bearing housing. 4 Nm
13.4 Removing and installing wheel bearing/
wheel hub unit
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1332-
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
242 Rep. Gr.42 - Rear suspension
