– Tighten lock nut using tool insert 24 mm -V.A.G 1332/11- while
counterholding on track rod ball joint -1-.
– Check toe values again.
It is possible that the value will change slightly when lock nut is
tightened.
However, if the measured toe value lies within the tolerance, the
adjustment is correct.
– Fit spring-type clip to boot.
Specified torques
Component Specified torque
Track rod ball joint to track rod 50 Nm
8.11 Basic setting for steering angle sender -
G85-
If steering wheel was realigned, basic settings for steering angle
sensor -G85- must be checked. ⇒ Perform basic settings in gui‐
ded fault finding using vehicle diagnosis, testing and information
system -VAS 5051- .
Select “Select function/component” by pressing Go to button.
8.12 Vehicle data sticker
Explanation of “PR numbers” on vehicle data sticker
Various types of running gear are installed depending on engine
and equipment level. These are identified by the PR numbers.
The PR numbers are critical in determining the wheel alignment
specifications.
The running gear version fitted in the vehicle is indicated on the
vehicle data sticker by the PR number for the front axle.
The vehicle data sticker can be found in the spare wheel well and
in the service booklet.
Example of a vehicle data sticker
In this example the vehicle is equipped with the standard running
gear G02 -arrow-.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
8. Wheel alignment 317
