12 - Ventilated brake disc
13 - Bolt
❑ M16 x 1.5 x 80
❑ Hexagon bolt, 200 Nm and turn +180° further
❑ 12-point bolt, 70 Nm + 90° further
❑ Always renew after removing
When bolt is loosened or tightened, vehicle must not be standing on its wheels
14 - Bolt
❑ Torque setting ⇒ Brake systems; Rep. Gr. 46 ; Repairing front brake .
15 - Wheel hub with wheel bearing (4-point mounting)
❑ Removing and installing ⇒ page 58
❑ The ABS sensor ring is installed in the wheel hub
❑ Various versions
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
16 - Wheel bearing housing (4-point mounting) - FN3 brakes
❑ Removing and installing ⇒ page 60
❑ With bolted-on brake carrier.
❑ If wheel bearing housing is renewed, wheels must be aligned ⇒ page 305 .
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
17 - Multi-point socket head bolt
❑ M12 x 1.5 x 45
❑ 70 Nm + 90° further
❑ Always renew after removing
18 - Drive shaft
❑ Removing and installing ⇒ page 77
19 - Nut
❑ M12 x 1.5
❑ 70 Nm + 90° further
❑ Self-locking
❑ Always renew after removing
4.1 Removing and installing wheel bearing
housing (3-point mounting)
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1332-
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
4. Assembly overview - wheel bearing 57
