Prerequisite: the positions of the subframe and brackets fixed
before they were removed
⇒ page 16 .
8.2 Test prerequisites
• Check suspension, wheel bearing, steering and steering link‐
age for excessive play and damage.
• Tread depth difference of no more than 2 mm on one axle.
• Tyres inflated to correct pressure.
• Vehicle unladen.
• Fuel tank must be full.
• Spare wheel and vehicle tools are stowed in correct locations.
• The fluid reservoir for the windscreen/headlight washer sys‐
tem must be full.
• When checking wheel alignment, ensure that sliding plates
and turn tables are not touching end stop.
Please note!
• The test equipment must be properly adjusted and attached
to the vehicle; observe device manufacturer's operating in‐
structions.
If necessary, contact the manufacturer for familiarisation with the
proper use of the wheel alignment equipment.
Wheel alignment platforms and wheel alignment units and com‐
puters can lose their calibration over a period of time.
Wheel alignment platforms and alignment units and computers
should be checked and adjusted as necessary during inspection
and maintenance at least once per year!
– Treat these highly sensitive units carefully and conscientious‐
ly!
8.3 Test preparations
Special tools and workshop equipment required
♦ Brake pedal actuator -V.A.G 1869/2-
The existing lateral runout of the wheel must be compensated for.
Otherwise, the result of the measurement will be incorrect.
If runout compensation is not performed, it is not possible to adjust
toe-in correctly!
Observe information provided by the manufacturer of the wheel
alignment unit.
– Carry out wheel run-out compensation.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
8. Wheel alignment 307
