92 VW Golf & GTI Quick Reference Specication Book • September 2012
Fastener Tightening Specications
Component Nm
Accessory bracket-to-cylinder block bolt 25
Air conditioning compressor-to-accessory bracket bolt 25
Air conditioning compressor ribbed belt tensioner-to-
accessory bracket bolt
35
Axial bearing disc-to-cylinder block bolt 10
Belt tensioner to accessory bracket 35
Bracket-to-cylinder block bolt 25
Brake booster vacuum pump-to-control housing cover
bolt
10
Connecting rod bearing cap-to-connecting rod bolt
1) 4)
30 plus an
additional 90°
(¼ turn)
Control housing cover-to-cylinder block bolt 25
Coolant pipe bolt/nut 10
Coolant pump-to-cylinder block bolt 10
Cover plate to cylinder block bolt 10
Crankshaft bearing cap-to-cylinder block bolt
1)
40 plus an
additional 90°
(¼ turn)
Crankshaft/vibration damper pulley-to-crankshaft bolt
1) 2)
50 plus an
additional 90°
(¼ turn)
Cylinder block locking bolt 45
Double chain sprocket (drive wheel)-to-cylinder block
bolt
1)
60 plus an
additional 90°
(¼ turn)
Drive plate/ywheel-to-crankshaft bolt
1)
60 plus an
additional 90°
(¼ turn)
Engine mount-to-accessory bracket bolt 40 plus an
additional 90°
(¼ turn)
Engine Speed (RPM) sensor-to-control housing cover
bolt
5
Exhaust camshaft sprocket-to-camshaft bolt
1)
60 plus an
additional 90°
(¼ turn)
Generator and coolant pump ribbed belt tensioner-to-
accessory bracket bolt
35
Intake camshaft adjuster-to-camshaft bolt
1)
60 plus an
additional 90°
(¼ turn)
Intake manifold support/oil dipstick guide tube-to-cylinder
block bolt
25
