Manual Trans. –

0A4

VW Golf & GTI Quick Reference Specication Book • September 2012 115

Reverse Shaft Support to Transmission Housing

Bolt Tightening Sequence and Specication

Step Component Nm

Tighten bolt a Æ

2 Tighten bolt b (lower illustration 20

3 Tighten bolt c 25
