24
VW Golf & GTI Quick Reference Speciîš¿cation Book
•
September 2012
Accessory Bracket T
ightening Speciîš¿cations
Step
Component
Nm
1
T
ighten bolts 1 through 6 in sequence
Hand-tighten
2
T
ighten bolts 1 through 6 in sequence
40
3
T
ighten bolts 3 and 4
an additional
45° (⅛ turn)
4
T
ighten bolts 1, 2, 5 and 6
an additional
90° (¼ turn)
35
37
