132 VW Golf & GTI Quick Reference Specication Book • September 2012

Transmission to Engine Tightening Specications

Component Fastener

size

Drive plate-to-converter - 60

Bolts M12 80 or 65, if

using T10179

Bolts located in the lower ange M10 40

Æ Alignment pins for centering
