Body
VW Golf & GTI Quick Reference Specication Book • September 2012 167
Tunnel Bridge, Plenum Chamber
Tightening Speciîš¿cations
Component Nm
Plenum chamber bulkhead bolts/nuts 8
Tunnel bridge bolts 20
Front Hood Tightening Speciîš¿cations
Component Nm
Front hood hinge bolt/nut 22
Hood latch bolts 12
Striker pin bolts 10
Rear Lid, Fuel Filler Door Tightening Speciîš¿cations
Component Nm
Angle bracket 10
Fuel îš¿ller door unit screws 1.5
Rear lid gas strut ball head pin 20 plus an
additional 90°
(¼ turn)
Rear lid hinge bolts 10
Rear lid hinge nuts 24
Rear lid lock bolts 23
Rear lid latch screws 12
Rear lid striker pin bolts 18
Front and Rear Door Tightening Speciîš¿cations
Component Nm
Door clamp screws 8
Door hinge bolts
1)
10
28
38
50
Door lock bolts 20
Door regulator motor bolts 3.5
Door striker pin bolts 20
Door trim screws 2
Front door mounting bracket screw 1
Rear door îš¿xed window bolts 8
Rear door mounting bracket 4.5
Window regulator bolts 8
Window regulator motor bolts 3.5
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Front or Rear Door Hinge
Assembly Overview.
