Engine –
2.0L CRZA
VW Golf & GTI Quick Reference Specication Book • September 2012 69
Fastener Tightening Speciîš¿cations
Component Nm
Air conditioning compressor-to-accessory bracket bolt 25
Coolant pump-to-cylinder block bolt 15
Coolant thermostat housing-to-cylinder block bolt 15
Connecting rod bearing cap-to-connecting rod bolt
1)
45 plus an
additional 90°
(¼ turn)
Crankshaft bearing cap-to-cylinder block bolt
1)
65 plus an
additional 90°
(¼ turn)
Crankshaft toothed belt gear-to-crankshaft bolt
1)
90 plus an
additional 90°
(¼ turn)
Dual mass ywheel-to-crankshaft bolt
1)
60 plus an
additional 90°
(¼ turn)
Engine mount bracket-to-cylinder block bolt 45
Engine Speed (RPM) sensor-to-cylinder block bolt 10
Generator-to-accessory bracket bolt/nut 23
Idler roller-to-cylinder head bolt 25
Idler roller-to-sealing ange bolt 35
Intake manifold support-to-cylinder block bolt 23
Knock Sensor (KS)-to-cylinder block bolt
3)
20
Lower toothed belt guard-to-cylinder block bolt 8
Oil îš¿lter adapter-to-cylinder block bolt
1)
15 plus an
additional 90°
(¼ turn)
Pressure relief valve bolt 27
Rear toothed belt guard-to-cylinder head bolt
2)
10
Ribbed belt tensioner-to-accessory bracket bolt 23
Sealing ange-to-cylinder block bolt 15
Sensor wheel-to-crankshaft screw
1)
10 plus an
additional 90°
(¼ turn)
Sprocket-to-camshaft bolt
1)
50 plus an
additional 90°
(¼ turn)
Toothed belt tensioner-to-cylinder head stud bolt nut 25
Upper toothed belt guard-to-cylinder head bolt 10
Vibration damper-to-crankshaft bolt
1)
20 plus an
additional 90°
(¼ turn)
1)
Replace fastener(s).
2)
Install using locking uid.
3)
The tightening speciîš¿cation affects the function of the Knock Sensor (KS).
