248 VW Golf & GTI Quick Reference Specication Book • September 2012
DTC CHART
Engine Codes CBTA, CBUA
Fuel and Air Mixture,
Additional Emission Regulations
DTC Error Message Malfunction Criteria and
Threshold Value
P000A Intake Camshaft Position Slow
Response Bank 1
• Difference between target and
actual > 8° CRK for > 1.8 to
2.5 Sec.
• Adjustment angle < 3° CRK
rotation
P0010 Intake Camshaft Position
Actuator Circuit Open Bank 1
Signal voltage > 4.70 - 5.40 V
P0011 Intake Camshaft Position
Timing - Over-Advanced Bank
1
• Difference between target and
actual > 8° CRK rotation
• Adjustment angle < 3° CRK
rotation
P0016 Camshaft Position Sensor
Angular Offset Check
Permissible deviation < -13.49
or >13.49 CRK deg.
P0030 HO2S Heater Control Circuit
Bank 1 Sensor 1
• O2S signal rear not oscillating
at reference < 598 mV and
enrichment after stuck lean
20%
• or
• Heater voltage 4.70 to 5.40 V
P0031 HO2S Heater Control Circuit
Low Bank 1 Sensor 1
• O2S signal rear not oscillating
at reference < 598 mV and
enrichment after stuck lean
20%
or
• Heater voltage 0 to 3.26 V
P0032 HO2S Heater Control Circuit
High Bank 1 Sensor 1
Heater current > 5.50 A
P0036 HO2S Heater Control Circuit
Bank 1 Sensor 2
Heater voltage 2.34 to 3.59 V
P0037 HO2S Heater Control Circuit
Low (Bank 1, Sensor 2)
Heater voltage < 2.34 V
P0038 HO2S Heater Control Circuit
High (Bank 1, Sensor 2)
Heater voltage > 3.59 A
