38 VW Golf & GTI Quick Reference Specication Book • September 2012
Engine Assembly – 2.0L CBFA, CCTA
Fastener Tightening Specications
Component Fastener
size
Nm
Bolts and nuts M6 10
M7 15
M8 25
M10 40
M12 60
Engine mount bracket-to-engine bolt
1)
- 40 plus an
additional 180°
(½ turn)
Engine mount-to-body bolt
1)
- 40 plus an
additional 90°
(¼ turn)
Engine mount-to-engine mount bracket
bolt
1)
- 60 plus an
additional 90°
(¼ turn)
Pendulum support-to-subframe bolt
1) 2)
- 100 plus an
additional 90°
(¼ turn)
Support-to-body bolt
1)
- 20 plus an
additional 90°
(¼ turn)
Engine mount support bolt
1)
- 20 plus an
additional 90°
(¼ turn)
Transmission mount-to-body bolt
1)
- 40 plus an
additional 90°
(¼ turn)
Transmission mount-to-transmission mount
bracket bolt
1)
- 60 plus an
additional 90°
(¼ turn)
1)
Replace fastener(s).
2)
Install the pendulum support-to-transmission bolts rst, then the pendulum support-
to-subframe bolt.
