138 VW Golf & GTI Quick Reference Specication Book • September 2012
Controls, Housing (DSG) – 02E
Fastener Tightening Speciîš¿cations
Component Nm
Bevel box-to-transmission bolt
2)
40
Drive axle heat shield-to-bevel box bolt
2)
25
Mechatronic cover bolt
1)
16
Oil îš¿lter housing 20
Oil pump cover bolt
1)
8
Overow tube-to-transmission 3
Selector housing-to-body nut 8
Selector lever cable adjustment bolt 13
Selector mechanism with selector lever and selector
lever cable-to-body bolt
8
Selector shaft lever nut 20
Transmission drain plug 45
Transmission input speed and clutch oil temperature
sensor bolt
10
Transmission oil cooler-to-transmission bolt 20 plus an
additional 90°
(¼ turn)
Wire bracket-to-Mechatronic cover nut 10
1)
Tighten the bolts diagonally and in multiple stages.
2)
R32 models only.
