110 VW Golf & GTI Quick Reference Specication Book • September 2012
Controls, Housing – 0A4
Fastener Tightening Specications
Component Fastener
size
Nm
5
th
gear drive gear-to-output shaft bolt - 80 plus an
additional 90°
(¼ turn)
5
th
gear selector fork base-to-transmission
housing bolt
- 25
5
th
gear shift jaw-to-selector fork with rail
bolt
- 25
Backup lamp switch-to-shift unit - 20
Cable bracket-to-transmission bolt - 20
Flange shaft bolt - 25
Gear shift unit with selector cover-to-
transmission housing bolt
- 25
Oil drain plug-to-clutch housing - 35
Oil ll plug-to-transmission housing - 35
Output shaft bearing mount-to-clutch
housing nut
1)
- 25 plus an
additional 90°
(¼ turn)
Sealing cap-to-transmission housing bolt - 25
Reverse gear selector fork-to-clutch
housing bolt
- 25
Selector bracket-to-pin bolt
2)
- 5
Shift housing-to-body nut M6 8
M8 25
Shift lever guide cover-to-shift housing
bolt
2)
- 5
Shift lever-to-shift unit nut
1)
- 23
Support pin-to-transmission housing bolt - 25
Synchronizer hub with drive gear and
synchronizer ring for 5
th
gear plate spring-
to-input shaft bolt
1)
- 80 plus an
additional 90°
(¼ turn)
Transmission housing-to-clutch housing
bolt
1)
- 25 plus an
additional 90°
(¼ turn)
Transmission housing cover-to-
transmission housing bolt
- 18
1)
Replace fastener(s).
2)
For shift levers and housings through 10.06.
