Automatic Trans. –
09G
VW Golf & GTI Quick Reference Specication Book • September 2012 131
Controls, Housing
Fastener Tightening Speciîš¿cations
Component Nm
Inspection plug-to-transmission oil pan 27
Multifunction transmission range switch-to-shift rod nut 7
Multifunction transmission range switch-to-transmission
bolt
6
Selector lever-to-selector shaft nut 13
Selector housing-to-body nut 8
Selector lever cable adjustment bolt 15
Selector lever and selector mechanism with selector
lever cable-to-body bolt
8
Transmission mount bracket-to-transmission bolt 40 plus an
additional 90°
(¼ turn)
Transmission mount-to-transmission mount bracket bolt 60 plus an
additional 90°
(¼ turn)
