22 VW Golf & GTI Quick Reference Specication Book • September 2012
Crankshaft, Cylinder Block – 2.0L CJAA
(TDI)
Fastener Tightening Specications
Component Nm
Air conditioning compressor-to-accessory bracket bolt 25
Bracket-to-oil lter bracket bolt 10
Camshaft sprocket-to-camshaft bolt 20 plus an
additional 45°
(⅛ turn)
Center toothed belt guard-to-lower toothed belt guard
bolt
1)
10
Connecting piece-to-cylinder block bolt 15
Connecting rod cap-to-connecting rod bolt
1) 4)
30 plus an
additional 90°
(¼ turn)
Coolant pump-to-cylinder block bolt 15
Crankshaft bearing cap-to-cylinder block bolt
1)
65 plus an
additional 90°
(¼ turn)
Crankshaft toothed belt gear-to-crankshaft bolt
1)
120 plus an
additional 90°
(¼ turn)
Engine speed sensor-to-cylinder block bolt 5
Flywheel-to-crankshaft bolt
1)
60 plus an
additional 90°
(¼ turn)
Generator-to-accessory bracket bolt 25
High pressure pump-to-accessory bracket bolt 20 plus an
additional 90°
(¼ turn)
High pressure pump toothed belt gear-to-hub bolt
1)
20 plus an
additional 90°
(¼ turn)
Hub-to-camshaft bolt 100
Hub-to-high pressure pump nut 95
Idler pulley-to-accessory bracket bolt 50 plus an
additional 90°
(¼ turn)
Idler roller-to-accessory bracket bolt 15
Oil lter bracket-to-cylinder block bolt
1) 3)
15 plus an
additional 90°
(¼ turn)
Oil pan-to-cylinder block bolt 15
Oil spray jet-to-cylinder block bolt 25
