Clutch – 0A4
Fastener Tightening Speciîš¿cations
Component Fastener
size
Nm
Ball stud-to-transmission - 25
Clutch pedal bolt nut
1)
- 25
Clutch pedal bracket-to-bulkhead nut
1)
- 25
Clutch slave cylinder-to-transmission bolt - 20
Guide sleeve-to-transmission bolt - 20
Hose/line assembly bracket-to-transmission
bolt
- 20
Impact bolster support-to-steering column bracket
- Secured with two bolts - 10
- Secured with one bolt - 20
Pressure plate-to-ywheel bolt
2)
M6 13
M7 20
Transmission support-to-transmission
bracket/transmission bolt
1)
- 20 plus an
additional 90°
(¼ turn)
1)
Replace fastener(s).
2)
Loosen and tighten in small steps and in a diagonal sequence.
