166 VW Golf & GTI Quick Reference Specication Book • September 2012
Body Exterior
Bulkhead, Front Fender Tightening Speciîš¿cations
Component Nm
Bulkhead bolts 25
Front fender bolts 6
Front fender brace bolts 6
Lock Carrier Tightening Speciîš¿cations
Component Nm
Air guide channel bolts 2
Angle bracket bolts 8
Cross member bolts
1)
8
60
Guide piece bolts 5
Lock carrier support bolts 12
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Lock Carrier Overview, items 13
and 14.
Underbody Trim, Noise Insulation
Tightening Speciîš¿cations
Component Nm
Anchor bracket bolt 20
Noise insulation bolts
1)
2
6
Rear retaining strip bolt 70
Right side angle bracket
- Nut 20
- Bolt 35
Underbody cover bolt 2
Underbody cover lock washer 1.5
Underbody trim panel, center nuts 1.5
Underbody trim panel, center bolts 2
Underbody impact guard
2)
2
20
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Noise Insulation Overview, items
13 and 14.
2)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Underbody Impact Guard
Overview.
