Engine –
2.0L CJAA (TDI)
VW Golf & GTI Quick Reference Specication Book • September 2012 31
Lubrication – 2.0L CJAA (TDI)
Fastener Tightening Speciîš¿cations
Component Nm
Chain tensioner with tensioning rail-to-cylinder block bolt 15
Oil îš¿lter bracket cap 25
Oil îš¿lter bracket connection 30
Oil îš¿lter bracket cover 25
Oil îš¿lter bracket-to-cylinder block bolt
1) 2)
15 plus an
additional 90°
(¼ turn)
Oil level thermal sensor-to-oil pan bolt 10
Oil pan drain plug
1)
30
Oil pan-to-cylinder block bolt 15
Oil pan-to-transmission bolt 40
Oil pressure switch-to-oil îš¿lter bracket 22
Oil pump sprocket-to-oil pump bolt 20 plus an
additional 90°
(¼ turn)
Oil spray jet-to-cylinder block bolt 25
Oil supply line clamp bolt 10
Oil supply line îš¿tting-to-connection 22
Oil supply line îš¿tting-to-turbocharger 22
Sealing ange-to-cylinder block bolt 15
Suction pipe-to-oil pump bolt 15
Windage tray-to-cylinder block bolt 15
Wiring harness bracket-to-oil îš¿lter bracket bolt 10
1)
Replace fastener(s).
2)
Tighten the upper left and lower right bolts îš¿rst and then tighten all four bolts in a
diagonal sequence.
