26 VW Golf & GTI Quick Reference Specication Book • September 2012
Cylinder Head, Valvetrain – 2.0L CJAA
(TDI)
Fastener Tightening Specications
Component Nm
Adapter to cylinder head bolt 10
Camshaft Position (CMP) sensor-to-cylinder head bolt 10
Camshaft sprocket-to-camshaft bolt 20 plus an
additional 90°
(¼ turn)
Center toothed belt guard to lower toothed belt guard bolt
1)
10
Coolant pump to cylinder block bolt 15
Crankshaft toothed belt gear to crankshaft bolt
1)
120 plus an
additional 90°
(¼ turn)
Engine mount bracket to cylinder block bolt
1)
40 plus an
additional 180°
(½ turn)
Fuel rail-to-cylinder head cover bolt 22
Heat shield-to-cylinder head cover bolt 5
High pressure pump toothed belt gear-to-hub bolt
1)
20 plus an
additional 90°
(¼ turn)
Hub-to-camshaft bolt 100
Lifting eye-to-cylinder head bolt/stud bolt 25
Protective plate to rear toothed belt guard bolt 5
Rear toothed belt guard to cylinder block bolt
2)
10
1)
20
Sealing cap-to-cylinder head cover bolt 5
Tensioning plate-to-cylinder head cover nut 10
Toothed belt idler pulley to cylinder block bolt
1)
50 plus an
additional 90°
(¼ turn)
Toothed belt idler roller to cylinder block bolt/nut 20
Toothed belt tensioner-to-cylinder block nut 20 plus an
additional 45°
(⅛ turn)
Vacuum pump-to-cylinder head bolt 10
Vibration damper-to-crankshaft bolt
1)
10 plus an
additional 90°
(¼ turn)
1)
Replace fastener(s).
2)
For bolt tightening clarication, refer to ElsaWeb, Toothed Belt Overview, items 14
and 15.
