32 VW Golf & GTI Quick Reference Specication Book • September 2012
Cooling System – 2.0L CJAA (TDI)
Fastener Tightening Speciîš¿cations
Component Nm
4/2 way valve with thermostat-to-cylinder block bolt 15
Coolant expansion tank to body stud bolt 5
Coolant fan shroud nut 5
Coolant pump-to-cylinder block bolt 15
Coolant reservoir-to-body stud bolt 3
Cylinder block connecting piece bolt 15
Engine pre-heater coolant pipe/engine pre-heater
bracket to cylinder block bolt
10
Radiator fan shroud bolt 5
Radiator bolt 5
Ventilation pipe-to-intake manifold bolt 10
Fuel Supply – 2.0L CJAA (TDI)
Fastener Tightening Speciîš¿cations
Component Nm
Accelerator pedal module-to-body bolt 10
Exhaust pressure sensor 1 bracket bolt 8
Fuel îš¿ller door unit-to-body bolt 1.5
Fuel îš¿ller tube-to-body bolt 10
Fuel îš¿lter cover-to-fuel îš¿lter housing bolt (Version A) 8
Fuel îš¿lter cover-to-fuel îš¿lter housing bolt (Version B) 5
Fuel îš¿lter housing-to-body bolt/nut 10
Fuel tank securing strap-to-body bolt
1)
25
Fuel tank-to-body bolt
1)
25
Fuel tank locking ring 110
1)
Replace fastener(s).
