Suspension,
Wheels, Steering
VW Golf & GTI Quick Reference Specication Book • September 2012 149
Wheel Alignment Data
Wheel Alignment Specied Values
Front suspension Basic suspension Sport suspension
without 18” wheels/
GTD without 18”
wheels/
GTD with adaptive
chassis DCC without
18” wheels
Production Relevant No.
(PR. No.)
2UA G58, 2UC
Total toe
(wheels not pressed)
10’ ± 10′ 10’ ± 10′
Camber
(wheels in straight ahead
position)
-30′ ± 30′ -41′ ± 30′
Maximum permissible
difference between both
sides
30’ 30’
Toe-out angle
1)
with
steering wheel turned 20°
to left and right
1°38′ ± 20′ 1°40′ ± 20′
Caster 7° 34′ ± 30′ 7° 47′ ± 30′
Maximum permissible
difference between both
sides
30’ 30’
Standing height 382 ± 10 mm 367 ± 10 mm
