196 VW Golf & GTI Quick Reference Specication Book • September 2012
DTC CHART
Engine Codes CCTA
Fuel and Air Mixture,
Additional Emission Regulations
DTC Error Message Malfunction Criteria and
Threshold Value
P000A Intake (A) Camshaft Position
Slow Response Bank 1
Signal change < 1.9 - 4.2°CRK/s
P0010 Intake (A) Camshaft Position
Actuator Circuit/Open
(Bank 1)
Signal voltage > 4.4 - 5.6 V
P0011 Intake (A) Camshaft Position
Timing - Over-Advanced
(Bank 1)
Target error (stuck position)
> 6.8 - 8°CRK
P0016 Crankshaft Position -
Camshaft Position Correlation
(Bank 1, Sensor A)
• Permissible deviation
< 11° Rev
or
• Permissible deviation
> 11° Rev
P025A Fuel Pump Open Circuit Signal voltage > 4.4 - 5.6 V
P025C Fuel Pump Short to Ground Signal voltage < 2.15 - 3.25 V
P025D Fuel Pump Short to B+ Signal current > 1.1 A
P0030 HO2S Heater Control Circuit
(Bank 1, Sensor 1) Open
Circuit
Heater voltage 2.34 - 3.59 V
P0031 HO2S Heater Control Circuit
Low (Bank 1, Sensor 1)
Heater voltage < 2.34 V
P0032 HO2S Heater Control Circuit
High (Bank 1, Sensor 1)
Heater voltage > 3.59 V
P0036 HO2S Heater Control Circuit
(Bank 1, Sensor 2)
Heater voltage 4.50 - 5.50 V
P0037 HO2S Heater Control Circuit
Low (Bank 1, Sensor 2)
Heater voltage < 3.00 V
P0038 HO2S Heater Control Circuit
High (Bank 1, Sensor 2)
Heater current 2.70 - 5.50 A
