168 VW Golf & GTI Quick Reference Specication Book • September 2012
Sunroof Tightening Speciîš¿cations
Component Nm
Slotted guide rail bolts 5
Sunroof insulation unit bolts 8
Sunroof motor screws 3.5
Sunroof spring glider bolts 1.8
Sunshade motor screws 3.5
Front Bumper Tightening Speciîš¿cations
Component Nm
Bumper carrier bolts
1)
8
60
Bumper cover bolts 1.5-2
Side guide assembly bolts 2-5
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Front Bumper Carrier Overview,
items 2, 3, and 4.
Rear Bumper, Trailer Hitch Tightening Speciîš¿cations
Component Nm
Rear bumper carrier bolts
1)
8
20
Rear bumper cover bolts 2
Trailer hitch bolts
2)
20
50 plus an
additional 90°
(¼ turn)
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Rear Bumper Carrier Overview,
items 2 and 5.
2)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Trailer Hitch Overview, items 3
and 4.
Mirror Tightening Speciîš¿cations
Component Nm
Adjusting motor screw 1
Mirror base bolts 10
Mirror frame 1
Exterior Equipment Tightening Speciîš¿cations
Component Nm
Sill panel extension and cover bolts 1.2-2
Wheel cover trim bolts 2
Wheel housing liner bolts 2
