124 VW Golf & GTI Quick Reference Specication Book • September 2012
Rear Final Drive, Differential – 02Q
Fastener Tightening Specications
Component Fastener
Size
Nm
Flange shaft to threaded piece bolt - 33
All Wheel Drive Fastener Tightening Specications
Component Fastener
size
Nm
Backup lamp switch-to-transmission
housing
- 20
Bevel box-to-clutch housing
1)
- 40 plus an
additional 90°
(¼ turn)
Bevel box-to-transmission
1)
- 40 plus an
additional 45°
(⅛ turn)
Cable mounting bracket-to-transmission
bolt/nut
- 20
Gear shift unit-to-transmission housing bolt
1)
- 20
Heat shield/driveshaft-to-bevel box - 25
Locking bolt to transmission housing - 45
Oil ll or drain plug
- Multipoint socket head - 45
- Hex socket head - 30
Right head shield/driveshaft to bevel gear - 20
Shift housing to body nut M6 8
M8 25
Transmission uid ll plug
1)
- 15
Transmission housing-to-clutch housing
bolt
1)
- 15 plus an
additional 90°
(¼ turn)
Transmission shift lever-to-shift unit nut
1)
- 23
1) Replace fastener(s).
