Body

VW Golf & GTI Quick Reference Specication Book • September 2012 163

BODY

Air Gap Body Dimensions

Body, Front

Component mm

a 4.5 ± 0.5

b 3.5 ± 0.5

c 0.5 ± 0.5

d 3.5 ± 0.5

e 5.0 ± 0.5
