OM ET18/20/24 us 1.3 * et18_20_24b510.fm 5-37
5
➥ The check pin K must be fully retracted.
Setting down an attachment
Crushing hazard due to uncontrolled movements of the
attachment!
Can result in severe injury or death.
► Do not allow anyone to stay in the danger zone.
► Lower the attachment to level and firm ground ensuring
stability.
1. Lower the attachment to about 5 – 10 cm (2 – 4 in) above the ground.
2. Actuate switch 39.
➥ The buzzer sounds.
3. Press and hold foot-operated pushbutton switch 3.
4. Pull and hold stabilizer-blade lever 8 as far as it will go.
➥ The quickhitch opens and unhitches the attachment.
Fig. 179: Retracted check pin
K
Fig. 180: Easy Lock switch
39
Fig. 181: Foot-operated pushbutton switch and
stabilizer-blade lever
3
8
