OM ET18/20/24 us 1.3 * et18_20_24i400.fm 4-35
4
Symbol Designation
High speed (2nd speed)
Illuminates with high speed enabled.
Charge indicator light
This indicator light illuminates if the electrical system has a malfunction.
The battery is no longer or insufficiently charged.
Note: This indicator light also illuminates if the starting key is turned to
position 2. The indicator light goes out after the engine is started.
Increase engine speed if the indicator light illuminates. The electrical
system works if the indicator light of the electrical system goes out within
one minute.
Engine oil pressure
The indicator light illuminates and the buzzer sounds.
• Stop the engine immediately and check the oil level.
• If the engine oil level is correct, contact a Wacker Neuson service
center.
Note: The indicator light illuminates when the starter is turned on and
goes out as soon as the engine runs.
At low temperatures, the indicator light can illuminate for more than 10
seconds after the engine is started.
Preheating
The indicator light illuminates if the starting key is in position 2. The indi-
cator light goes out after 4 seconds and the engine can be started.
(A glow plug preheats the air in the combustion chamber of the engine
when the key is in this position.)
Contact a Wacker Neuson service center if the indicator light does not go
out.
Safe load indicator light
The safe load indicator gives the operator optical and acoustic warnings
when the values of the stability table are reached or exceeded.
• Reduce reach or the lift load until both the acoustic signal and the
indicator light in the display element go out.
Engine temperature
If the coolant temperature segment reaches the red range, the indicator
light illuminates and the buzzer sounds.
Stop and let the engine cool down before starting it again.
Changeover between hour meter and maintenance counter
