OM ET18/20/24 us 1.3 * et18_20_24t600.fm 6-3
6
6.2 Loading the machine
Information regarding loading
Accident hazard due to incorrect loading!
Incorrect loading can result in accidents and severe injury or
death.
► Ensure that no one is in the danger zone.
► Read the transport weight off the type label. Add the weight of
subsequently installed equipment to the weight of the
machine.
Engine damage due to incorrect engine oil level.
► The oil level must be visible at the MAX mark.
Traveling onto transport vehicles
Preparatory work
1. Secure the transport vehicle with chocks to prevent it from rolling.
2. Position the ramps at the smallest possible angle. Ensure that the
grade does not exceed 15° (27 %).
3. Use access ramps with an antiskid surface only.
4. Ensure that the loading area is clear and access to it is not obstructed
– due to superstructures, for example.
Traveling onto transport vehicles
1. Remove the shatter protection if the machine is transported on an
open platform.
2. Start the engine of the machine.
3. Raise the attachment and the stabilizer blade to avoid touching the
ramps.
4. Carefully travel the machine onto the middle of the transport vehicle.
5. Move the machine to transport position.
6. Stop the engine.
7. Raise the control lever base.
8. Remove the starting key and carry it with you.
9. Leave the cab, close and lock all doors, windows and covers.
10.Secure and tie down the machine.
Fig. 215: Access ramps
< 15°
Fig. 216: Transport position
