RJ-901C/RJ-900C Maintenance Manual 4 Parts Replacement
4-61
3. Detach the cable from the cover (L/R) sensor cable-retaining clamp.(The diagram below shows the cover
R sensor).
4. Replace the cover sensor assembly.
5. To reassemble the unit, reverse the removal procedure.
No. Part name
1 Clamp
2
Cover R sensor cable
1
2
