3 Specifications RJ-901C/RJ-900C　 Maintenance Manual
3-8
3.3.2 Network Interface Specifications
3.4 Options/Supplies List
3.4.1 Options
(1) Stand
(2) Other Options
TIP
The scroller is supplied with the movable media stopper.
Item Specifications
Network type Ethernet IEEE802.3
Network I/F 10BASE-T / 100BASE-TX Auto-switching
(RJ-45 connector twist pair cable )
MDI / MDI-X Auto-switching
Corresponding
protcol
TCP/IP, ARP, RARP, ICMP
Name Model Sales units
Optional stand for RJ-901 RJ9-STD 1 box (includes
one set)
Name Model Sales units
Scroller (flange diameter: 2 in.) RJ3-3R12 1 box (1 piece per
box)
Scroller (flange diameter: 3 in.) RJ3-SR13 1 box (1 piece per
box)
3-inch spacer RJ9-FS03 1 box (2 pieces per
box)
