Maintenance
WorkCentre 5019/5021
User Guide
10-7
Replacing the drum cartridge
The following error codes and icons display in the machine status diagram when the drum cartridge is
near the end of its service life.
Contact your local Xerox representative or sales representative to have your drum cartridge replaced.
Error code Status machine diagram Required action
- When the drum cartridge icon is lit (blinks
for three seconds), the drum cartridge will
need to be replaced after about 1,000
pages
*1
. Have a replacement drum
cartridge ready.
J-4 When this error code appears, the drum
cartridge icon starts blinking, and the error
icon is lit, the drum cartridge needs to be
replaced. Replace the drum cartridge.
J-7 When this error code appears and the drum
cartridge icon is lit, the warranty period for
the image quality on the drum cartridge
has expired.
