Yamaha WaveRunner FX SHO Service Manual

5-4
E
POWR
1
2
3
4
5
6
7
8
9
Engine unit removal 2
Step
Procedure/Part name
Q’ty Service points
1 Fuel hose assembly 1 È To fuel pump module
2 Plastic tie 2
3 Clamp/breather hose 2/1
4 Connection 1
NOTE:
Align the mark a on the connection with the
mark b on the intake pipe.
5 Clamp/intake pipe 2/1
6 Air filter case cover 1
7Screw 3
8 Air filter element 1
9Bolt 4
A
15
16
17
18
1
14
4
a
b
7
9
9
11
11
8
6
5
5
13
12
3
3
10
19
18
16
17
2
È
É
É
Ê
Ë
10 N
·
m (1.0
kgf
·
m, 7.4 ft
·
Ib)
6 × 12 mm
13 N
·
m (1.3 kgf
·
m, 9.6 ft
·
Ib)
8 × 35 mm
6 × 15 mm
18 N
·
m (1.8 kgf
·
m, 13.3 ft
·
Ib)
LT
242
LT
242
LT
242
6 × 10 mm
6 N
·
m (0.6 kgf
·
m, 4.4 ft
·
Ib)
A
E
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
Engine unit

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
