Yamaha WaveRunner FX SHO Service Manual

5-34
E
POWR
1
2
3
4
5
6
7
8
9
Intake assembly removal
Step
Procedure/Part name
Q’ty Service points
Fuel injector Refer to “Fuel tank removal” in Chapter 4.
1 Plastic tie 1
2 Intake air temperature sensor 1
3 Washer 1
Not reusable
4 Clamp/hose 2/1
5Bolt 2
6 Intake air pressure sensor 1
7Bolt 2
8Bracket 1
9 Collar/grommet 2/2
10 Bolt 2
13
10
11
12
10
1
5
6
8
9
2
3
4
7
14
11
19
18
12
9
15
17
16
5 N
·
m (0.5
kgf
·
m, 3.7 ft
·
Ib)
6 × 25 mm
3.5 N
·
m (0.35
kgf
·
m, 2.6 ft
·
Ib)
5 × 15 mm
LT
572
15 N
·
m (1.5 kgf
·
m, 11.1 ft
·
Ib)
6 × 12 mm
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
1st 23 N
·
m (2.3 kgf
·
m, 17.0 ft
·
Ib)
2nd 42 N
·
m (4.2 kgf
·
m, 31.0 ft
·
Ib)
8 × 40 mm
1st 23 N
·
m (2.3 kgf
·
m, 17.0 ft
·
Ib)
2nd 42 N
·
m (4.2 kgf
·
m, 31.0 ft
·
Ib)
8 × 25 mm
2nd 20 N
·
m (2.0 kgf
·
m, 14.8 ft
·
Ib)
1st 10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
8 × 35 mm
2nd 20 N
·
m (2.0 kgf
·
m, 14.8 ft
·
Ib)
1st 10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
2nd 20 N
·
m (2.0 kgf
·
m, 14.8 ft
·
Ib)
1st 10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
LT
242
LT
242
LT
242
LT
242
LT
242
19
18
Air cooler, supercharger, and throttle body assembly
