Yamaha WaveRunner FX SHO Service Manual

1-2
E
GEN
INFO
1
2
3
4
5
6
7
8
9
Symbols
Symbols 1 to 9 are designed to indicate the
content of a chapter.
1 General information
2 Specification
3 Periodic check and adjustment
4 Fuel system
5 Power unit
6 Jet pump unit
7 Electrical system
8 Hull and hood
9 Trouble analysis
Symbols 0 to E indicate specific data.
0 Special service tool
A Specified oil or fluid
B Specified engine speed
C Specified tightening torque
D Specified measurement
E Specified electrical value
(resistance, voltage, electric current)
Symbols F to I in an exploded diagram indi-
cate the grade of lubricant and the lubrication
point.
F Apply 4-stroke motor oil
G Apply water resistant grease
(Yamaha grease A)
H Apply ThreeBond 1104J or ThreeBond 1280B
I Apply molybdenum disulfide grease
Symbols J to N in an exploded diagram indi-
cate the type of sealant or locking agent and
the application point.
J Apply Gasket Maker
K Apply LOCTITE 271 (red)
L Apply LOCTITE 242 (blue)
M Apply LOCTITE 572
N Apply silicone sealant
NOTE:
Additional symbols may be used in this man-
ual.
12
34
56
78
90
AB
CD
EF
GH
IJ
KL
MN
GEN
INFO
SPEC
CHK
ADJ
FUEL
POWR
JET
PUMP
– +
ELEC
HULL
HOOD
TRBL
ANLS
T
R
.
.
E
A
1280B1104J
M
GM
271
LT
242
LT
572
LT
SS
How to use this manual

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
