1-30
E
GEN
INFO
1
2
3
4
5
6
7
8
9
Large intermediate housing and oil seal
In order to handle the high output, the intermediate housing has been strengthened. Furthermore,
lipped oil seals have been adopted to improve waterproofing.
1 Oil seal
2 Intermediate housing
3 Driven coupling
Intake grate
The grate of the intake grate has been changed to 3 bars and the components have been combined
into a single part. This improves serviceability. In addition, the transom plate and spacer have been
combined into a single part, which improves the rigidity and serviceability of the part.
1 Intake grate
2 Transom plate
3
1
2
1 2
Feature and benefit
