Yamaha WaveRunner FX SHO Service Manual

8-5
E
HULL
HOOD
Step
Procedure/Part name
Q’ty Service points
10 Left handlebar switch assembly 1
NOTE:
Align the projection a on the handlebar
switch assembly with the handlebar hole b.
11 Bolt 2
NOTE:
Tighten the upper bolt first when installing
the right handlebar switch assembly.
12 Right handlebar switch assembly 1
13 Handlebar 1
14 Screw 4
A
LT
242
LT
242
12
11
13
14
12
4
10
5
6
7
3
2
1
6 × 10 mm
1 N
·
m (0.1 kgf
·
m, 0.7 ft
·
Ib)
1 N
·
m (0.1 kgf
·
m, 0.7 ft
·
Ib)
5 × 35 mm
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
6 × 70 mm
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
5 × 35 mm
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
5 × 25 mm
1
2
15
1
2
8
3
16
10
9
18
15
14
14
14
21
22
20
17
A
19
21
19
20
b
a
5 × 35 mm
1 N
·
m (0.1 kgf
·
m, 0.7 ft
·
Ib)
LT
242
7 N
·
m (0.7 kgf
·
m, 5.2 ft
·
Ib)
LT
242
Handlebar

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
