Yamaha WaveRunner FX SHO Service Manual

E
SPEC
2-20
1
2
3
4
5
6
7
8
9
A
B
I
J
G
9
M
E
N
K
L
8
O
D
5
Q
0
P
6
3
1
F
4
9
2
C
H
7
I Electric bilge pump coupler
J Negative battery cable
K Positive battery cable
L Battery breather hose
M Cooling water hose (jet pump to hose joint 1)
N Flushing hose
O Cooling water hose (hose joint 1 to hose joint 3)
P Buzzer lead
Q Compass and air temperature sensor lead (FX
Cruiser SHO)
Cable and hose routing

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
