YASKAWA E-V Series Selection Manual

6.3 User-Assembled Wiring Materials for Servomotor Main Circuit Cables
6.3.3 Standard-Structure Servomotor Connectors for 850 W to 15 kW
6-12
6.3.3 Standard-Structure Servomotor Connectors for 850 W
to 15 kW
 Connector Structures
For Servomotors without Holding Brakes
Note: 1. Servomotor Connectors (receptacles) are compatible with MS Connectors. If you prepare your own cables,
refer to the model number of MS connector in parentheses and select the appropriate plug.
2. Yaskawa does not specify what wiring materials to use. Use appropriate wiring materials for the current
specifications and connectors.
Servomo-
tor Model
Capacity
Servomotor Connec-
tor Model (Receptacle)
Order Number
Manu-
facturer
Straight Plug
Right-Angle Plug
Cable Clamp
Japan
Aviation
Elec-
tronics
Indus-
try, Ltd.
SGM7G-09
SGM7G-13
SGM7G-20
850 W to
1.8 kW
CE05-2A18-10PD-D
(MS Connector model:
MS3102A18-10P)
N/MS3106B18
-10S
N/MS3108B18
-10S
N/MS3057
-10A
SGM7G-30
SGM7G-44
2.9 kW to
4.4 kW
CE05-2A22-22PD-D
(MS Connector model:
MS3102A22-22P)
N/MS3106B22
-22S
N/MS3108B22
-22S
N/MS3057
-12A
SGM7G-55
SGM7G-75
SGM7G-1A
SGM7G-1E
5.5 kW to
15 kW
CE05-2A32-17PD-D
(MS Connector model:
MS3102A32-17P)
N/MS3106B32
-17S
N/MS3108B32
-17S
N/MS3057
-20A
Cable Clamp Cable
Straight Plug
Right-Angle Plug
Servomotor
Connector
(receptacle)
A
B
C
D
