4.2 Servomotor Main Circuit Cables
4.2.2 Servomotor Main Circuit Cables for Servomotors with Holding Brakes
4-10
Wiring Specifications
Note: There is no polarity for the connection to the holding brake.
SGM7A-30
3.0 kW
Straight
Standard
Cable:
JZSP-
UVA631--
E
Flexible Cable:
JZSP-
UVA641--
E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA601-
-E
Flexible Cable:
JZSP-UVA621--E
• Holding Brake
Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-
UVA632--
E
Flexible Cable:
JZSP-
UVA642--
E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA602-
-E
Flexible Cable:
JZSP-UVA622--E
• Holding Brake
Cable
*2
JZSP-U7B24--E
SGM7A-
40, -50
4.0 kW,
5.0 kW
Straight
Standard
Cable:
JZSP-
UVA731--
E
Flexible Cable:
JZSP-
UVA741--
E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA701-
-E
Flexible Cable:
JZSP-UVA721-
-E
• Holding Brake
Cable
*2
JZSP-U7B23--E
Right-
angle
*1
Standard
Cable:
JZSP-
UVA732--
E
Flexible Cable:
JZSP-
UVA742--
E
• Main Circuit Power
Supply Cable
Standard Cable:
JZSP-UVA702-
-E
Flexible Cable:
JZSP-UVA722-
-E
• Holding Brake
Cable
*2
JZSP-U7B24--E
*1. The lead installation direction is away from the load.
*2. Flexible Cables are provided as a standard feature.
For 50 W to 1.0 kW For 1.5 kW to 5.0 kW
Continued from previous page.
Servomotor
Model
Connector
Typ e
External Dimensions
Order Num-
bers of Main
Power Sup-
ply Cable and
Holding Brake
Cable
Individual Cable Order
Numbers
L
SERVOPACK end
Motor end
L
SERVOPACK end Motor end
L
SERVOPACK end Brake end
L
SERVOPACK end Motor end
Brake end Motor end
L
PinSignal
SignalWire Color
1
2
3
4
5
6
Servomotor Connecto
Phase U
Phase V
Phase W
FG
Brake
Brake
Brake
Brake
Phase U
Phase V
Phase W
FG
Red
White
Blue
Green/yellow
Black
Black
SERVOPACK Leads
PinSignal
SignalWire Color
A
B
C
D
Servomotor Connector
FG
Phase W
Phase V
Phase U
FG
Phase W
Phase V
Phase U
Green/yellow
Blue
White
Red
SERVOPACK Leads
1
2
Brake
Brake
Brake
Brake
Black
White
To Next Page
