4.3 User-Assembled Wiring Materials for Servomotor Main Circuit Cables
4.3.3 IP67-Structure/European-Safety-Standard-Compliant Servomotor Connectors for 1.5 kW to 7.0 kW
4-18
4.3.3
IP67-Structure/European-Safety-Standard-Compli-
ant Servomotor Connectors for 1.5 kW to 7.0 kW
Cables with connectors on both ends that are compliant with an IP67 protective structure and
European Safety Standards are not available from Yaskawa for SGM7A Servomotors. You must
make such a cable yourself.
Use the Connectors specified by Yaskawa for these Servomotors. (These connectors are com-
pliant with the standards.) Yaskawa does not specify what wiring materials to use.
Connector Structures
Note: For the conduit grounding, contact the manufacturer of the conduit.
For Servomotors without Holding Brakes
Servomo-
tor Model
Capac-
ity
Servomotor
Connector
Model
(Recepta-
cle)
Order Number
Applica-
ble
Cable
Diame-
ter (Ref-
erence
Values)
[mm]
Manu-
facturer
Plug
Only
Straight
Plug
Right-Angle
Plug
Cable Clamp
SGM7A-15
SGM7A-20
SGM7A-25
1.5 kW
to
2.5 kW
CE05-2A18
-10PD-D
CE05-
6A18-
10SD-D
CE05-
6A18-
10SD-D-
BSS
CE05-
8A18-
10SD-D-
BAS
CE3057
-10A-1-D
10.5 to
14.1
DDK
Ltd.
CE3057
-10A-2-D
8.5 to
11.0
CE3057
-10A-3-D
6.5 to
8.7
SGM7A-30
SGM7A-40
SGM7A-50
SGM7A-70
3.0 kW
to
7.0 kW
CE05-2A22
-22PD-D
CE05-
6A22-
22SD-D
CE05-
6A22-
22SD-D-
BSS
CE05-
8A22-
22SD-D-
BAS
CE3057-12A-
1-D
12.5 to
16.0
DDK
Ltd.
CE3057-12A-
2-D
9.5 to
13.0
CE3057-12A-
3-D
6.8 to
10.0
CE3057-12A-
7-D
14.5 to
17.0
Plug
Conduit
Servomotor
Servomotor Connector
(receptacle)
Cable Clamp
(waterproof)
Cable
Cable
Straight Plug
(waterproof)
Right-Angle Plug
(waterproof)
A
B
C
D
