Fieldbus control with embedded fieldbus 317
1106 REF2
SELECT
COMM
COMM+AI
1
COMM*AI1
Fieldbus reference REF2 is used
when EXT2 is selected as the active
control location. See section
Fieldbus references on page 320 for
information on the alternative
settings.
40003 for REF2
OUTPUT SIGNAL SOURCE SELECTION ABB
DRV
DCU
1401 RELAY
OUTPUT 1
COMM
COMM(-1)
Enables relay output RO control by
signal 0134 COMM RO WORD.
40134 for signal
0134
1501 AO1
CONTENT
SEL
135 Directs the contents of the fieldbus
reference 0135 COMM VALUE 1 to
analog output AO.
40135 for signal
0135
SYSTEM CONTROL INPUTS ABB
DRV
DCU
1601 RUN
ENABLE
COMM Enables the control of the inverted
Run enable signal (Run disable)
through 0301 FB CMD WORD 1 bit 6
(RUN_DISABLE); with the ABB
drives profile 5319 EFB PAR 19 bit 3
(INHIBIT OPERATION).
40001
bit 3
40031
bit 6
1604 FAULT
RESET SEL
COMM Enables fault reset through the
fieldbus 0301 FB CMD WORD 1 bit 4
(RESET); with the ABB drives profile
5319 EFB PAR 19 bit 7 (RESET).
40001
bit 7
40031
bit 4
1606 LOCAL
LOCK
COMM Local control mode lock signal
through 0301 FB CMD WORD 1 bit
14 (REQ_LOCALLOC)
- 40031
bit 14
1607 PARAM
SAVE
DONE
SAVE…
Saves parameter value changes
(including those made through
fieldbus control) to permanent
memory.
41607
1608 START
ENABLE 1
COMM Inverted Start enable 1 (Start
disable) through 0302 FB CMD
WORD 2 bit 18 (START_DISABLE1)
- 40032
bit 18
1609 START
ENABLE 2
COMM Inverted Start enable 2 (Start
disable) through 0302 FB CMD
WORD 2 bit 19 (START_DISABLE2)
- 40032
bit 19
Parameter Setting for
fieldbus
control
Function/Information Modbus register
address
